CM70 HS
CM70 HS Plus is a high speed battery-powered ride-on polishing machine with direct drive.
Very comfortable and productive, it's ideal for polishing vinyl floors. It's a single disc machine equipped with a 36 Volt electrical system, so it's extremely productive and guarantees performance up to 4140 sq.m./h.
CM70 HS Plus is the ideal solution for restoring and keeping the shine on medium and large-size floors. It's also a polishing machine that's very easy to use, designed for use even by less experienced personnel.
It's equipped with a system for collecting the dust produced to ensure a professional result and increase productivity, making it a single disc machine suitable for working in the HoReCa, Health and Public sector.
Very comfortable and productive, it's ideal for polishing vinyl floors. It's a single disc machine equipped with a 36 Volt electrical system, so it's extremely productive and guarantees performance up to 4140 sq.m./h.
CM70 HS Plus is the ideal solution for restoring and keeping the shine on medium and large-size floors. It's also a polishing machine that's very easy to use, designed for use even by less experienced personnel.
It's equipped with a system for collecting the dust produced to ensure a professional result and increase productivity, making it a single disc machine suitable for working in the HoReCa, Health and Public sector.
-
Working width:
690 mm
-
Power supply:
battery
-
Drive:
direct
- Documents
- Request information
- FAQ
-
Working width:
690 mm
Power supply:
battery
Drive:
direct
- Documents
- Request information
- FAQ
CM 70 HS
Technical data
- Drive
Direct Drive - Working width (mm)
690 - Theoretical productivity (up to sqm/h)
4140 - Pad (mm)
Ø 690 - Pressure on the brush (min - max) (kg)
10 - 15 - Debris hopper capacity (l)
18.5 - Brush rotations (rpm)
1300 - Supply/traction (V)
36/aut. - Max. power (W-hp)
6100 - Net weight (kg)
336 - Machine dimensions (l x h x w) (mm)
1685x1370x680
CM 70 HS
Technical data
- Drive
Direct Drive - Working width (mm)
690 - Theoretical productivity (up to sqm/h)
4140 - Pad (mm)
Ø 690 - Pressure on the brush (min - max) (kg)
10 - 15 - Debris hopper capacity (l)
18.5 - Brush rotations (rpm)
1300 - Supply/traction (V)
36/aut. - Max. power (W-hp)
6100 - Net weight (kg)
336 - Machine dimensions (l x h x w) (mm)
1685x1370x680
Single disc machines CM70 HS Features
- Battery-powered ride-on single disc machine recommended for polishing vinyl floors in large spaces, with dust vacuum system
- Equipped with 69 cm pad holder
- Single disc machine with system for collecting the dust produced (which is conveyed into a disposable bag filter). In this way, the dust is completely collected, and prevented from settling on the furniture and walls
- When working, the single disc machine is electronically controlled to ensure the best maintenance and polishing result, even on uneven surfaces
- PM - Pressure Monitoring: system for monitoring the pressure on the brushes
- The brush head is automatically raised and lowered by an actuator connected to the gear
- Equipped with a vacuum cleaner that can be easily removed to clean the tank and filter
- The wide opening of the cover ensures good access to the battery compartment
- Equipped with soundproofing foam panels to allow the vacuum cleaner to be stopped while the cover is open
- Motorwheel with traction drive that allows an extremely tight curve radius, thus ensuring maximum maneuverability even in cluttered areas
- The forward speed of the CM70 HS Plus (up to 6 km/h) makes it highly productive
- Stop&Go: when the machine is temporarily idle, the brushes are halted so as to optimize consumption and reduce waste
