HP6000

Sweepers HP6000 Features

• Twin Action System: The mechanical action consists in the movement of the central brush (1) which collects the material from the ground and conveys it to a hopper where is shredded by a rotating shaft equipped with hammers (2). At this point, by means of the vacuum action (3), the material is raised to the collection hopper (4), while the sucked air is filtered (5) and returned to the environment perfectly clean (6).
• Saving more than 150,000 liters of water per year: unlike traditional sweepers, with HP6000 the side brushes have an auxiliary function (only used along edges and pavements), consequently reducing the use of water which is employed only in a nebulized state and only to control dust, without wetting the ground.
• Reduction of fuel consumption and atmospheric emissions thanks to the high performance hydraulic system and the EURO VI engine, specific for industrial applications, certified in accordance with the strictest atmospheric emissions standards in its category.
• Greater operator comfort and reduction of stress even during the longest work shifts thanks to the position of the engine, located at the rear of the vehicle, the sound proof cab and the use of hydraulic suspensions.
• The cleaning action is concentrated only on the central brush: the side brushes are used only to convey the dirt from the edges (pavements or walls) to the operating area of the central brush, which collects both debris and dust thanks to the highly efficient vacuum action.
• The technical solutions adopted, such as the hydraulic support and the presence of the flaps, ensure a constant pressure on the ground for the brush independently of wear or the terrain; the machine can also be positioned at 3 height levels allowing removal of different types of waste: leaves, pine needles, bottles, etc.
• The side brushes can be equipped with special nozzles for spraying water (optional) which are effective for controlling dust during sweeping
• Third brush (optional)
• Integral steering system on all 4 wheels with symmetrical front and rear angles (the same center of rotation for the two axles) and a turning circle of 4.945 m.
• Great maneuverability, even near walls or fences, guaranteed necessary ease of handling to operate in places where space is limited such as historical town centers or cluttered areas, at the same time guaranteeing maximum vehicle stability during transfer even at the highest speed.
• Traction is completely hydraulic, provided by two motors installed directly on the rear wheels and a variable capacity pump to adjust the speed from 0 to 40 km/h.
• The suspensions and the braking system guarantee driving in complete safety with excellent road holding, even when fully loaded.
• The coaxial turbine offers excellent vacuum performance and a significant reduction in maintenance
• Vacuum tube that allows specific operations as necessary. The operator can use the vacuum tube to collect material accumulated in areas difficult to be reached with the machine (benches, flowerbeds, covered corners, etc.); also, thanks to the large diameter of the hose, it can suck up waste of various dimensions such as paper, leaves, bottles and cans.
• Filtering unit with surface of 50 sq.m. and equipped with 2 electric filter shakers for cleaning. These characteristics, together with the choice of materials (polyester) and the fact that the filter operates dry, virtually eliminate the need for routine maintenance; they also ensure the return of perfectly clean air into the environment.
• By-pass system allowing deviation of the air flow in order to bypass the filter when working in wet road conditions, for example in the event of rain.
• High capacity (6 cu.m.) collection hopper which guarantees many hours of continuous non-stop operation.
• Ultra-reliable top emptying system at heights
• Comfortable, spacious cab, insulated with anti-vibration supports. Comfortable to drive, with large windscreen to provide maximum external visibility for the operator, making maneuvering and control over the collection area easier.
• The activation commands, simple and intuitive, are grouped on a central console. The others are on the front part of the armrest, both easily accessible from the working position.
• Maximum accessibility for simple quick maintenance operations
• The rear view camera allows the operator to check for obstacles when reversing
• Easy Fleet: the system that allows the most effective management of the fleet of Comac street sweepers possible and digitalization of sweeping operations
• Air conditioning
• Radio with CD player
• Rear color camera
• High pressure washer wand
• Emergency button to immediately stop the machine and all active functions in an emergency
